LABORATORY CALIBRATION EQUIPMENT
LABORATORY CALIBRATION EQUIPMENT 型號：PRESSURE AND VACUUM COMBITEST GENERATOR- Laboratory equipment suitable for calibration pressure meters and transmitters from 0 to 2000 mbar; differential and vacuum ones up to 1 mbar residual pressure
- Internal pressure and vacuum generators, manual or equipped with precision regulators
- Analog and digital pressure/vacuum scanners
-
APPLICATION
Calibrations of gauges 1 transmitters of pressure in the range -10001+2500 mbar), differential pressure and vacuum (up to 10-1).TECHNICAL CHARACTERISTICS (STANDARD VERSION)
PANEL PGD 01 - Digital measuring of pressure
n. 1 internal digital gauge for measuring relative and differential pressure as well as vacuum, digital display 4 ½ digit
Range: -11+2,5 bar, accuracy 士 0.05% fs. 士 1 digit at +20 °C
Measurement units: bar, psi, MPA, KPA, mbar
(Other range: -11+1 bar, -11+5 bar, 01+10bar also with combination of 2 manometers) -
RACK unit 19"
- Metal structure (15/10)
- Epoxy paint RAL7030
- Aluminium printed front panels
- Voltage：230V - 50 Hz.
- Pneumatic supply：8 bar max with a rear 2 stage filter and a line reducer
- Weight：46 Kg
- Dimension：515 x 400 x 600 mm
