LKZ-720

• Detection of wires and cables (live or not)
  • detection of cables in ceilings, walls and floors,
  • detection of breaks in cables,
  • tracing cables in building installation,
  • locating power points and switches in buildings,
  • locating short circuits between leads,
  • tracing shielded cables,
  • tracing cables in metal ducts.
• Identification of fuses on the distribution board.
• Tracing underground cables.
• Tracing conductive water and heating pipelines.
• Non-contact detection of live cables.

Features:

• the function 3D in the receiver - detecting the direction of current flow and accurate locating the object,
• phase detection mode,
• receiver operation with four transmitters at the same time to locate interruptions or distinguish wires,
• a LED bright torch,
• headphone socket in receiver,
• screens backlight for work in dark,
• transmission battery status and settings of the transmitter to the receiver
• operation in wide range of rated voltage, up to 500V RMS,
•  measurement of voltage at the object to 500 Vrms,
• three levels of transmitter amplification,
• automatic or manual selection of transmitter operation modes,
• five modes of wire tracer operation - voltage, current, current-voltage, power and clamp,
• software upgrade via USB,
• additional accessories enable precise localization - such as contact or non-contact probes and measurement clamp.

Electric security:

• type of insulation: double, according to EN 61010-1
• measurement category: CAT III 600V acc. to EN 61010-1
• transmitter’s protection class acc. to EN 60529: IP67
• receiver’s protection class acc. to EN 60529: IP40

Other technical data:

• transmitter’s power supply: four AA alkaline battery or NiMH rechargeable battery
• transmitter’s max working voltage: 500 Vrms (707 Vampl)
• detector’s max range („I” mode) 2m
• non-contact neon max range: 20 cm (in air), 3 cm (in concrete)
• receiver’s power supply: battery 9V 6LR61 alkaline

Rated operational conditions:

• operating temperature -10°C...+50°C
