Calport 100 或 Calport 100 Plus 測試軟體
PC Software for a Calport 100 or Calport 100 Plus tester 型號：Calsoft 100-
- reading actual measured values from the Calport 100 using RS232C interface and their visualisation on PC screen. The readings can be done automatically by user defined period of time,
- reading data, earlier stored in analyser’s memory (up to 40 sets of data) and their visualisation on PC screen,
- visualisation of three phase vector chart,
- export of measured data to Microsoft Excel, which enables later their processing according to the user’s requirements.
- printing data and charts on the printer, • saving and reading data to and from files for making archives of measurements.
-
Function / parameter
Range
Error 1) 2) 3) 6)
class 0.1
class 0.2
Direct voltage
30…480V
0.05...30V±0.1%
±0.1%*±0.2%
±0.2%*Voltage with VoltLiteWire
0.5…40kV
±0.1%±Em ±0.2%±Em
Direct current
0.04…12A
0.001…0.04A±0.1%
±0.1%*±0.2%
±0.2%*Current with clamps 10A
0.1…10A
0.005…0.1A±0.5%
±0.5%*±0.5%
±0.5%*Current
with clamps 100A0.5…100A
0.01…0.5A±0.2%
±0.2%*±0.2%
±0.2%*Current
with clamps 1000A20…1000A
0.1…20A±0.5%
±0.5%*±0.5%
±0.5%*Current
with clamps 3000A60…3000A
0.3…60A±1%
±1%*±1%
±1%*Current with flex
0...30A/300A/3000A
±0.1%±Em ±0.2%±Em
Current
with AmpLiteWire30…2000A
±0.1%±Em ±0.2%±Em
Power and energy direct measure
0.04...12A / 30...480V
0.001........ A / 30…480V±0.1%
±0.1%*±0.2%
±0.2%*Power and energy with clamps 10A
0.1...10A / 30...480V
0.005...... A / 30…480V±0.5%
±0.5%*±0.5%
±0.5%*Power and energy with clamps 100A
0.5...100A / 30...480V
0.01...... A / 30…480V±0.2%
±0.2%*±0.2%
±0.2%*Power and energy with clamps 1000A
20…1000A / 30...480V
0.1...20A / 30…480V±0.5%
±0.5%*±0.5%
±0.5%*Power and energy with clamps 3000A
60…3000A / 30...480V
0.3…60A / 30…480V±1%
±1%*±1%
±1%*Power and energy
with flexible clamps0...30A/300A/3000A /
30...480V±0.1%±Em ±0.2%±Em
Power and energy
with clamps LiteWire30…2000A / 0.5…40kV
±0.1%±Em
±0.2%±Em
Resolution of energy meter error measurement "e"
0.0001%
0.0001%
Phase shift direct connection with clamps
0...±360°
±0.4° 4)
±0.5° 5)±0.4° 4)
±0.5° 5)Power factor
cos j and sin j0.000...±1.000
±0.01
±0.01
Frequency
45...65Hz
±0.05Hz
±0.05Hz
Ambient temperature
-5...+50°C operating, -20...+60°C transportation
Power supply
85..230..265V / DC or 45..65Hz / 10VA
Dimensions and weight of analyser
270 / 240 / 180 mm / 3.5 kg
Dimensions of analyser set
420 / 280 / 370 mm
1) % - related to the measuring value, %* - related to the measuring final value
2) Em-sensor basic error, Em=1%+0,1%* for flexible clamps and Em=2%+0,2%* for LiteWire sensors
3) Power and energy errors related to apparent power
4) In current range 0,04…12A and in voltage range 30…480V
5) From 10% of current range and in voltage range 30…480V
6) Power and energy errors is doubled for input wiring 3 phase 3 wire (Aron measuring system)
