50dB 射頻屏蔽織物
50dB RF Shielding-Fabric 型號：Aaronia Shield Series
透明度非常高的RF屏蔽材料解決方案非常適合阻尼高度達到50dB（99.999%）的產品，如窗戶，服裝，遮罩帳篷，醫療應用等設備。
-
透明度非常高的RF屏蔽材料解決方案非常適合阻尼高度達到50dB（99.999%）的產品，如窗戶，服裝，遮罩帳篷，醫療應用等設備。
Aaronia新出品的EMC和RF屏蔽織物是由獲得專利的高科技屏蔽纖維材料而製成的，具備高透明度，易洗，防腐等功能。 是製作RF視窗防護，窗簾，防護服，屏蔽帳篷燈設備的最佳選擇。該產品可以防護任何一種射頻，防止任何類型的射頻「電磁污染」，並提供屏蔽性能和保護，對於高GHz範圍內的設備（行動電話，微波爐，航空雷達，軍事廣播等）都具備超高的屏蔽保護性能。根據權威專家進行的專項調查顯示，Aaronia的此款產品可能是迄今為止世界上最佳的射頻屏蔽產品，具備高透明的屏蔽纖維。如果產品配備Aaronia提供的接地元件，那麼對於由電源線，電纜線等引起的低頻電磁場也具備很好的屏蔽功效。同時，產品簡單實用，易於上手。德國製造所有Aaronia的屏蔽材料都是在德國研發製造的，因此保證了產品的高品質。功能特點- 高度透氣性。
- 非常輕。
- 透明度高。
- 可像處理布料一樣處理。
- 防腐。
- 防凍。 防靜電。
- 防腐劑（減少細菌和氣味等）。
- 可清洗。
- 可折疊。
-
單位長度 0.7 m, 7 m, (1 m², 10 m²) ，亦可提供指定切割尺寸的成品 寬度 1.4 m 厚度 0.1 mm 網格尺寸 0.7 mm 顏色 銀色 重量 約27 g/m² 網格材料 高性能銀/聚醯胺化合物（20%/80%） 篩選性能 - 靜態磁場 99.99% to 99.999% （僅在接地情況下） 篩選性能 - 低頻磁場 99.99% to 99.999%（僅在接地情況下） 篩選性能 - 射頻 10 GHz 時為 43 dB (99.992%)，1 GHz 時為 50 dB (99.999%)（即使沒有接地） -
Very transparent RFI screening solution for windows, clothes, screening tents, medical applications with very high damping up to 50dB (99,999%).
Aaronia's novel EMC and RF Shielding-Fabrics Aaronia-Shield® is made from a patented high-tech shielding-fibre. Highly transparent, washable, antiseptic, most effective rf-shielding. Optimal for building rf shielding-canopies and emc emi shielding-chamber, fly screens, curtains, cloth, rf protective clothing etc. Protects against any kind of rf "electrosmog" and offers shielding-performance and protection especially in the high GHz range (mobile phones, microwave ovens, aviation radar, military broadcast, etc.). This product probably by far offers the world's best rf-shielding-performance among the highly transparent screening fabrics, according to the special survey conducted by Prof.We generally recommend using our grounding package for stationary applications to provide protection against LF electric fields caused by high-voltage lines, power cables, etc
They can be set up and dismantled easily and quickly, making them perfect for use even at changing locations.Made in GermanyAaronia Shielding Solutions are developed, manufactured, tested, and calibrated in Germany, guaranteeing the highest possible quality.Features- Highly permeable to air
- Very light
- Very transparent
- Can be handled like cloth
- Rot-proof
- Frost-proof
- Anti-static
- Antiseptic (reduces bacteria, smell etc.)
- Washable
- Foldable
-
Length per unit 0.7 m, 7 m, (1 m², 10 m²) Also available as cut good Lane width 1.4 m Thickness 0.1 mm Mesh size 0.7 mm Colour silver Weight approx. 27 g/m² Mesh material High-performance silver/polyamid compound (20%/80%) Screening performance - static fields 99.99% to 99.999% (only with grounding) Screening performance - low-frequency, electric fields 99.99% to 99.999% (only with grounding) Screening performance - high-frequency fields 43 dB (99.992%) at 10 GHz and 50 dB (99.999%) at 1 GHz (even without grounding)
