固定式保全應用紅外線熱像儀

SATIR IR Fixed Security Camera 型號：SATIR JK362-PoE

為固定式紅外線熱像儀，提供2種機型：乙太網路供電機型（PoE）及非乙太網路供電機型。

加入洽詢

產品特點產品規格 Features Specifications

- 為固定式紅外線熱像儀，提供2種機型：乙太網路供電機型（PoE）及非乙太網路供電機型。
- 具有384x288像素解析度紅外線偵測器，可產生110,592個像素，能提供侵入者及車輛的清楚影像。
- 標準配備9mm鏡頭，可偵測的人、車距離分別為266m及831m；提供選購的鏡頭包括：13mm、19mm、35mm、50mm。
- 採數位影像增強處理技術，能提供更清晰的影像品質。
- 乙太網路供電機型（PoE）特點：
  - 可透過乙太網路雙絞線傳輸電力和資料，因此，經由單條電纜即可提供數據連接及電源給例如無線網路存取點設備及IP攝影機。
  - 使用者可將資料儲存在USB儲存裝置。
  - 使用者可使用PTZ介面，控制攝影機。
- 自動追蹤警報功能，可提供終端使用者關於犯罪行為的警報。
- 機殼具IP66防護等級，能耐受振動及撞擊，
- 具自動加熱器，可防止鏡頭上結冰，因此，可於嚴寒環境下操作；適用的環境溫度範圍-35°C~ +65°C。
- 主要特點：
  - 384×288像素紅外線偵測器。
  - 提供多種可選購的鏡頭組態配置。
  - 適用於既有的安全網路（PoE機型）。
  - 自動警報追踪軟體。
  - 無線網路連線（PoE機型）。
  - USB儲存（PoE機型）。
  - IP66防護等級。
- 偵測器類型：非致冷式焦平面陣列微輻射熱測定器。
- 偵測器解析度：384x288像素。
- 熱靈敏度（N.E.T.D）：0.05°C @ 30°C。
- 光譜範圍：8～14µm。
- 焦距/視野（FOV）：
  - 9mm：60° x 44°（標配）。
  - 13mm：42° x 31°。
  - 19mm：28° x 21°。
  - 35mm：14° x 10°。
  - 50mm：11° x 8°。
- 對焦：免對焦消熱差鏡頭。
- 影像更新率：50/60Hz。
- 影像格式：PAL/NTSC複合視訊、H264網路數位視訊。
- 影像處理：自動增益控制、數位影像細節增強處理技術（DDE）。
- 機殼防護等級：IP66。
- 自動加熱器：從視窗除冰。
- 電源：12V DC或乙太網路供電。
- 功耗（加熱/一般）：≤ 35W/ ≤ 8W（有溫度控制時）。
- 啟動時間：≤ 60s。
- 介面：
  - AV輸出：選購。
  - RJ45乙太網路：有。
  - 警報輸入/輸出：有/有。
- 重量：3kg。
- 體積：362 x 140 x 145mm。
- 詳細規格、配件、軟體及選購，歡迎洽詢。
- There are two versions of the JK362 fixed security camera, there is one with PoE or no PoE. On the model without PoE not all features are available that are mentioned in this description, please refer to the specification for further details on the technical differences between the two models.
- The JK362/PoE has a 384x288 IR detector resolution which generates 110592 pixels which means it will give a clear image of intruders and vehicles.
- The 9mm lens is the standard lens that comes with this IR security camera. It can detection a people at 266m and vehicles are detected at 831m. There are other optional lens available on request they include; 13mm,19mm,35mm,50mm.
- It has digital enhancement technology which contributes to a clearer thermal image.
- To further explain the PoE model, POE stands for Power over Ethernet describes any of several standardized or ad-hoc systems which pass electric power along with data on twisted pair Ethernet cabling. This allows a single cable to provide both data connection and electric power to devices such as wireless access points and IP cameras.
- The PoE model also has USB storage available that will allow users to save data on USB storage devices.
- Users are also able to control the camera with the PTZ interface that is available on the PoE model.
- The automatic tracking alarm function is very useful to alert the end-user of criminal activity.
- It able to stand vibrations and shocks due to its IP66 Encapsulation.
- The JK362 has an automatic heater which will prevent the build-up of ice on the lens, meaning it can survive in cold conditions.
- It can operate in environments where temperature ranges vary from -35°C~ +65°C.
- Features:
  - 384×288 IR Detector
  - Diverse Optional Lens Configuration
  - Compatible with existing security networks (PoE Model)
  - Automatic alarm tracking software
  - Wi-Fi Connection (PoE Model)
  - USB Storage (PoE Model)
  - IP66
- Detector Type: FPA, Uncooled Microbolometer
- Detector Resolution: 384x288
- Thermal Sensitivity: 0.05°C @ 30°C
- Spectral Range: 8-14um
- Focal Length/FOV:
  - 9mm: 60° x 44° (standard)
  - 13mm: 42° x 31°
  - 19mm: 28° x 21°
  - 35mm: 14° x 10°
  - 50mm: 11° x 8°
- Focusing: Focus Free athermal lens
- Frame Rate: 50Hz/ 60Hz
- Image Format: PAL/NTSC Composite Video, H264 Network Digital Video
- Image Processing: Automatic Gain Control (AGC) Digital Detail Enhancement (DDE)
- Encapsulation: IP66
- Automatic Heater: De-icing from the window
- Power Requirements: 12V DC or PoE
- Power Consumption (heating/normal): ≤ 35W/ ≤ 8W (with temperature controlling)
- Start up Time: ≤ 60s
- Interfaces:
  - AV Out: Optional
  - RJ45 Ethernet: Yes
  - Alarm Input: Yes
  - Alarm Output: Yes
- Weight: 3kg
- Dimensions: 362mm x 140mm x 145mm
- Please feel free to contact for detailed specifications, accessories, software and options.
