便攜式電器|機械|開關裝置安規測試模擬示範板

Metrel PAT Demoboard 型號:MI 3300
  • 為教育或示範便攜式電器測試的絶佳示範板。只需輕按一下開關,便可在正常操作或故障模式下,模擬各種便攜式設備。
  • 可模擬不限數量的不同設備,並可設定故障條件,是在教室、訓練課程、示範課程、研討會及便攜式電器測試訓練課程中的理想工具。
  • 可在研討會及課程中,用於介紹電器、機械、開關裝置的完整安規測試。
  • 可透過使用不同的示範表,模擬實際不限數量的不同設備(標準配備8個示範表)。
  • 可依據需求,輕鬆地升級為使用新的示範表。
    • 為教育或示範便攜式電器測試的絶佳示範板。只需輕按一下開關,便可在正常操作或故障模式下,模擬各種便攜式設備。
    • 可模擬不限數量的不同設備,並可設定故障條件,是在教室、訓練課程、示範課程、研討會及便攜式電器測試訓練課程中的理想工具。
    • 可在研討會及課程中,用於介紹電器、機械、開關裝置的完整安規測試。
    • 可透過使用不同的示範表,模擬實際不限數量的不同設備(標準配備8個示範表)。
    • 可依據需求,輕鬆地升級為使用新的示範表。
    • 可開/關正常模式與故障模式,並提供用於學習評估的故障條件。
    • 可模擬以下故障:保護接地導通性故障、絕緣電阻故障、洩漏及接觸洩漏故障、極性及功能性故障。
    • 示範板是裝在附有提把的強固機箱內,可拆卸的上蓋,可供存放導線、轉接器與手冊。
    • 應用:
      • 在研討會及課程中,用於介紹電器、機械與開關裝置的完整安規測試。
      • 介紹電氣設備典型的安全問題。
      • 測量儀器的實際示範(執行測試、進行正確的連接、分析測量的結果)。
    • 符合標準:
      • 安全性:IEC/EN 61010-1。
    • 電源:230V/115V,50Hz(依據要求)。
    • 體積:350 x 335 x 160 mm。
    • 重量:7kg。
    • 詳細規格、配件、軟體及選購,歡迎洽詢。
    • The MI 3300 PAT Demoboard is an excellent instrument for teaching or demonstrating PAT testing.
    • The MI 3300 simulates a wide variety of portable equipment in normal operation or in fault conditions with the simple flick of a switch.
    • The ability of the unit to simulate unlimited number of different equipment and the possibility to set fault conditions make the PAT Demoboard the ideal unit for teaching or assessing learning in classrooms, training sessions, demonstration sessions, seminars and on PAT training courses.
    • Presentation of complete safety testing of electrical appliances, machines and switchgears in seminars, courses.
    • Practically unlimited number of different equipment can be simulated by using different tables (8 are included in a standard set).
    • On demand the demonstration board can be simply upgraded with new tables.
    • Normal and fault situations can be switched on and off, offering fault conditions for the assessment of learning.
    • Demoboard simulates the following faults: PE continuity faults, insulation resistance faults, leakage and touch leakage faults, polarity and functional faults.
    • The demonstration board is built into a strong rugged case with a handle and detachable lid for storing leads, adapters and manuals.
    • Application:
      • Presentation of complete safety testing of electrical appliances, machines and switchgears in seminars, courses.
      • Presentation of typical safety problems on electrical equipment.
      • Practical demonstration of measuring instruments (performing tests, making right connections, analysing measured results).
    • Standards:
      • Safety: IEC/EN 61010-1
    • Power supply: 230 V / 115 V (on request)
    • Dimensions: 350 x 335 x 160 mm
    • Weight: 7 kg
    • Please feel free to contact for detailed specifications, accessories, software and options.
