用於拉曼分析的光譜-電化學套件

MF-SPEC-ECKIT-4 是專為 PalmSens 客戶量身打造的光譜-電化學套件，客戶希望利用拉曼光譜擴展其電化學研究。此套件可讓使用者使用我們全新的 AvaSpec HERO 光譜儀 (788-1020 nm ) 進行完全同步的電化學與拉曼光譜混合原位分析檢測。這款具有低雜訊電子元件的高階冷卻背照式偵測器以及具有高數值孔徑的光具座可在近紅外線區域實現出色的雜訊比、動態範圍和更高的量子效率。此外，還包括我們的 AvaLaser 785 (內含：785 nm 雷射安全護目鏡) 以及用於光譜資料評估的高階「Panorama Light 軟體」，具有 2D/3D 資料視覺化、在庫中搜尋、在光譜庫中歸檔等功能。該套件還配備了緊密的比色皿固定座，可與 AvaLaser785 的拉曼探針配合使用，並配備了可調式鍍金鏡，用於收集信號。

MF-SPEC-ECKIT 的交貨範圍： 可根據要求提供所有零件

• AV-CUV-UV-VIS：比色皿支架，10 mm 路徑，包括 2 個 UV/VIS/NIR 準直透鏡和上蓋。 （Qt.1）
• AV-FO-UVIRCBL：光纜、600 μm UV/IR 寬頻光纖 (200-2500 nm)、1 m 長、SMA 端子、BX 金屬護套。隨附於 MF-SPEC-ECKIT (Qt.2)
• AvaSpec-HERO 光譜儀： AvaSpec-HSC1024x58TEC-EVO : 758nm 拉曼光譜系統，包含 (範圍：100 cm-1 - 3000 cm-1, 解析度：10 cm-1)
• AvaLaser 785 和探針
• AvaRaman/Panorama Light 軟體
• 安全護目鏡
• 與拉曼探針搭配使用的比色皿固定座，金色可調整
• 用於信號收集的鍍膜鏡面

• mf-spec-eckit-4b： 中階 Spectro-EC 拉曼套件，可使用較長的積分時間，同時保持熱雜訊限制 - 冷卻版本搭配 AvaRaman 光譜儀 - 範圍： 150 cm-1- 3600 cm-1 ；解析度： 6 cm-1。
• MF-SPEC-ECKIT-4：基本型 Spectro-EC 拉曼套件，作為強訊號的入門級解決方案 - 非冷卻型光譜儀，適用於強訊號 - 量程： 150 cm-1 - 3600 cm-1；解析度： 6 cm-1。

MF-SPEC-ECKIT-4: Spectro-EC Kit for Raman Analysis

The MF-SPEC-ECKIT-4 is a customized Spectro-Electrochemistry Kit made for our PalmSens customers wanting to expand their electrochemical research with Raman spectroscopy. This kit will allow users to conduct fully synchronous in-situ analysis for electrochemistry hybridized with Raman Spectroscopy using our new AvaSpec HERO Spectrometer (788-1020 nm) for detection. Such a high end cooled back-thinned detector with low-noise electronics, and an optical bench with high numerical aperture results in excellent signal to noise, dynamic range, and higher quantum efficiency in NIR region. Also included is our AvaLaser 785 (included: 785 nm laser safety goggles) and a high-end “Panorama Light Software” for spectroscopic data evaluation featuring 2D/3D data visualization, searching in libraries, archiving in spectral libraries, and more. The kit is also equipped with tight cuvette holder for use with Raman probe of AvaLaser785 with an adjustable gold coated mirror for signal collection.

Included: Ava-Raman-D (Highsense Bundle)

• Range: 100 cm-1 - 3000 cm-1; Resolution: 10 cm-1
• Spectrometer: AvaSpec-HSC1024x58TEC-EVO set for (788-1020 nm)
• Slit 25 (replaceable slit)
• FC-PC connector
• AvaLaser785 (integrated in probe)
• Raman software: Panorama Light

Customization: Contact us for a quote for either option.

• MF-SPEC-ECKIT-4B: Mid-Level Spectro-EC Raman Kit to work with longer integration times while keeping the thermal noise limited – Cooled version with AvaRaman Spectrometer - Range: 150 cm-1 - 3600 cm-1; Resolution: 6 cm-1
• MF-SPEC-ECKIT-4: Basic Spectro-EC Raman Kit as an entry level solution for strong signals – Uncooled Spectrometer for strong signals - Range: 150 cm-1 - 3600 cm-1; Resolution: 6 cm-1


Potentiostat Compatibility: MF-SPEC-ECKIT-4 is compatible only with the selected PalmSens Potentiostats / Galvanostats with auxiliary port options as PalmSens 4, EmStat4X and MultiPalmSens 4 series.

How to Order: Simply select any of the Potentiostat / Galvanostat from the compatible options above and add the following two items to the order. You are ready to conduct plug-n-play Vis-NIR region Spectro-EC Analysis from day one.
