GIUSSANI_NF-C_PQ

PRESSURE GAUGES

PRESSURE GAUGES 型號：NF-C
  • Ø150 mm dial pressure gauge
  • Pressure range: 0 ÷ 1000 bar
  • Accuracy: ±0,25 % f.s.
加入洽詢
Features Specifications

  • These instruments have been designed for laboratories, instrument testing or recalibration facilities and in other applications where accuracy and repeatability are of primary importance. Whenever is requested the conformity to safety normative EN 837-1 and ANSI B40. is possible to use the models NFC: these instruments have a solid separating wall in stainless steel, placed between the dial and the elastic element and an integral blow out back that is released from the case whenever a pressure is created inside the case, due to leaks or accidental ruptures of the elastic element. They can be used with fluids or gasses that do not have high viscosity and do not crystallize. The wetted parts in beryllium copper of model NFC permits higher accuracy.

    Each instrument is supplied with a calibration certificate that guarantee the traceability to the National and International master primary instruments. Upon request we can supply the calibration certificate issued by an Internationally recognized Accredia laboratory.

  • Accuracy class:
    Classe di precisione:    		 0,25 as per EN 837-1.
    0,25 secondo EN837-1.
    Ambient temperature:
    Temperaturaambiente:    		 +15…+65°C.
    Process fluid temperature:
    Temperaturadel fluido di processo:    		 max +65°C.
    Calibration temperature:
    Temperaturaditaratura:    		 +20°C.
    Working pressure:
    Pressionediesercizio:    		 max 75% of the full scale value.
    max 75% del V.F.S.
    Overpressure (referred to the full scale value):
    Sovrapressione:    		 25% for pressure ranges up tp 60 bar: 15% for pressure ranges more then 100 bar.
    25% del V.F.S. per campi fino a 60 bar;
    15% del V.F.S. per campi oltre 100 bar.
    Protection:
    Grado di protezione:    		 IP 55 as per IEC 529.
    IP 55 secondo IEC 529.
    Socket material:
    Perno di attacco al processo:    		 AISI 316L st.st.
    in AISI 316L.
    Elastic element:
    Mollatubolare:    		 beryllium copper.
    in rame al berillio.
    Welding:
    Saldatura:    		 silver alloy.
    in lega d’argento.
    Case diameter:
    Diametrocassa:    		 150 mm
    Case:
    Cassa:    		 AISI 304 st.st.
    in AISI 304.
    Ring:
    Anello:    		 AISI 304 st.st., bayonet lock.
    a baionetta, in AISI 304.
    Blow out disk:
    Fondodirompente:    		 AISI 304 st.st.
    in AISI 304.
    Window:
    Trasparente:    		 laminated safety glass.
    invetrodoppio stratificato.
    Movement:
    Movimento:    		 high precision type.
    diprecisione, in lega orologeria.
    Connection:
    Attaccoalprocesso:    		 ½” BSP M*
    Dial:
    Quadrante:    		 aluminium light green with, black markings and anti-parallax mirror band.
    in alluminio a fondo verde, con graduazioni
    enumerazioneinneroebanda antiparallasse.
    Pointer:
    Indice:    		 balanced, anti-parallax knife-edge micrometer adjustable.
    inalluminio anodizzatonero con
    azzeramento micrometrico e terminale a coltello.
    Gaskets:
    Guarnizioneal trasparenteeal fondello:    		 EPDM.
    Carring case:
    Custodia:    		 Plastic case with foam.
    Valigettainplasticacon gomma-spugna.
    Case dimension:
    Dimensionicustodia    		 310 x 180 x 120 mm
    Weigth
    Peso    		 2 Kg.
